Industrial Monitors

GlobalTech Display offers several model industrial monitors with different enclosures, and the screen sizes are from 8" to 21.5". We deliver the latest LCD true flat panel technology for harsh industrial environments.
SPECIFICATIONS
Feature Enclosure Aluminum alloy, Front panel IP65
Anti-static Contact 4kV, air 8kV (Can custom 16kV)
Anti-vibration 5-19Hz/1.0mm amplitude, 19-200Hz/1.0g acceleration
Impact resistance 10g acceleration, 11ms period
Anti-interference High EMI immunity
Interface DC input 1*DC 2pin connector, 11.6-28V
Video port HDMI, DVI, VGA
Touch panel connector RJ45 (USB)
Headphone jack 3.5mm
Audio port Audio I/O
Interface extension Supports customization of more interface ports
Display Specs Color 16.7M
Dot 0.264mm
Display High-end TN/IPS TFT LCD
Contrast 800:1
Brightness 300nit (Can custom ≥400nit)
Viewing angle 160°/160° (Can custom full view 178° )
Backlight type LED, lifetime ≥50,000h
Response 6.5ms
Touch panel option RTP/CTP
Installation type Desktop, wall-mounted
Environment Operation Temperature -10 °C ~ 60 °C （Can custom -30℃~80℃）
Storage Temperature -40 °C ~ 85 °C
Humidity 20%-95%
Power Supply Power ≤35W
AC Input AC100-240V  50/60Hz
Output DC12V/4A
PRODUCT LIST
Part Number Screen Size Resolution Screen Ratio
Product PN GLM080-M200, 300, 400, 500 8" 1024*768 4:3
GLM101-M200, 300, 400, 500 10.1" 1280*800 16:10
GLM104-M200, 300, 400, 500 10.4" 1024*768 4:3
GLM116-M200, 300, 400, 500 11.6" 1920*1080 16:9
GLM120-M200, 300, 400, 500 12" 1024*768 4:3
GLM150-M200, 300, 400, 500 15" 1024*768 4:3
GLM156-M200, 300, 400, 500 15.6" 1920*1080 16:9
GLM170-M200, 300, 400, 500 17" 1280*1024 5:4
GLM173-M200, 300, 400, 500 17.3" 1920*1080 16:9
GLM190-M200, 300, 400, 500 19" 1280*1024 5:4
GLM191-M200, 300, 400, 500 19.1" 1440*900 16:10
GLM215-M200, 300, 400, 500 21.5" 1920*1080 16:9
